ASTM A209 /A209M ASME SA209 tubes shall be made by the seamless process and shall be either hot-finished or cold finished as specified.
ASTM A209 /A209M covers several grades of minimum- wall-thickness, seamless, carbon-molybdenum alloy-steel, boiler and superheater tubes.
ASTM A209 /A209M covers tubes 1⁄2 to 5 in. [12.7 to 127 mm] inclusive, in outside diameter and 0.035 to 0.500 in. [0.9 to 12.7 mm], inclusive, in minimum wall thickness.
Standard: ASTM A209 /A209M, ASME SA209.
Description Name: ASTM A209 / ASME SA209 T1, T1a, T1b Seamless tubes, ASTM A209 T1 Superheater tubes, ASME SA209 T1 Superheater tubes. ASTM A209 T1 boiler tubes, ASTM A209 T1a Tubes, ASTM A209 T1b Tubes, Seamless superheater tubes, Boiler tubes.
Size:12.7 to 127 mm.
Wall Thickness: 0.9 to 12.7mm.
Shape: Round.
Length: Single random length/ Double random length or as customer’s actual request.
Grade: T1, T1a, T1b.
Referenced Documents:
ASTM A1016/A 1016M Specification for General Requirements for Ferritic Alloy Steel, Austenitic Alloy Steel, and Stain- less Steel Tubes.
| ASTM A209 / A209M ASME SA209 T1 T1a T1b Seamless Boiler and Superheater Tubes | |
| Outside diameter | 12.7mm ~ 127mm |
| Wall thickness | 0.5mm ~ 12.7mm |
| Length | Up to 25m |
| Standard | ASTM A106, A179, A192, A209 A210, A213,A269, A333, A335, DIN17175, EN10216-2, JIS3461, etc. |
| Grade | T1, T1a, T1b, TP304,TP304L,TP316, TP316L,T5, T9, T11, T22, etc. |
| Delivery Condition | Pickled, Polished, Bright Annealed |
| Technique | Seamless/Welded |
| Application | Heat-exchanger, Heater, Boiler, Condenser Equipment |
| Marking | LOGO, Standard, Grade, Size, Heat Number. |
| Package | Woven bag, wooden case or as per customer's requirement. |
| Quality Requirement | Mill Test Certificate (EN 10204/3.1); Third Part Inspection is acceptable. |
